Graphics: Integrated Graphics Processor+Intel® Thunderbolt™ 3 Controller: 2 x Intel® Thunderbolt™ 3 connectors (USB Type-C™ ports), supporting DisplayPort and Thunderbolt™ video outputs and a maximum resolution of 5120 x 2880@60 Hz with 24 bpp; * Because of the limited I/O resources of the PC architecture, the number of Thunderbolt™ devices that can be used is dependent on the number of the PCI Express devices being installed. (Refer to Chapter 1-7, "Back Panel Connectors," for more information.); * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.; Integrated Graphics Processor-Intel® HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz; * Support for HDMI 1.4 version and HDCP 2.3.; Maximum shared memory of 512 MB
CPU's supported: Support for 10th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/ Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1200 package
Chipset: Intel® Z490 Express Chipset
Expansion Slots: 1 x PCI Express x16 slot, running at x16 (PCIEX16); * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.; 1 x PCI Express x16 slot, running at x8 (PCIEX8); * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.; 1 x PCI Express x16 slot, running at x4 (PCIEX4); * The PCIEX4 slot shares bandwidth with the M2P_PCH connector. The PCIEX4 slot operates at up to x2 mode when an M.2 SSD is installed in the M2P_PCH connector.; (All of the PCI Express x16 slots conform to PCI Express 3.0 standard.); Supports up to ASPM L1.2 power management protocols.
Storage: 1 x M.2 connector (Socket 3, M key, type 2242/2280/22110 SATA and PCIe x4/x2 SSD support)(M2A_CPU); 1 x M.2 connector (Socket 3, M key, type 2242/2280/22110 SATA and PCIe x4/x2 SSD support)(M2M_PCH); 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2P_PCH); 6 x SATA 6Gb/s connectors; Support for RAID 0, RAID 1, RAID 5, and RAID 10; * Refer to "1-9 Internal Connectors," for the installation notices for the PCIEX4, M.2, and SATA connectors.; Intel® Optane™ Memory Ready; M.2 connectors support up to ASPM L1.2 PCIe power management protocols.
Memory type: Intel® Core™ i9/i7 processors: Support for DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz; Intel® Core™ i5/i3/Pentium®/Celeron® processors: Support for DDR4 2666/2400/2133 MHz; 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules
I/O: 1 x Q-Flash Plus button; 1 x Clear CMOS button; 2 x SMA antenna connectors (2T2R); 2 x Thunderbolt™ 3 connectors (USB Type-C™ ports, with USB 3.2 Gen 2 support); 4 x USB 3.2 Gen 2 Type-A ports (red); 2 x USB 3.2 Gen 1 ports; 2 x USB 2.0/1.1 ports; 1 x HDMI port; 2 x RJ-45 ports; 1 x optical S/PDIF Out connector; 5 x audio jacks
Connectors: 1 x 24-pin ATX main power connector; 2 x 8-pin ATX 12V power connectors; 1 x CPU fan header; 1 x water cooling CPU fan header; 4 x system fan headers; 2 x system fan/water cooling pump headers; 2 x addressable LED strip headers; 2 x RGB LED strip headers; 6 x SATA 6Gb/s connectors; 3 x M.2 Socket 3 connectors; 1 x noise detection header; 1 x front panel header; 1 x front panel audio header; 1 x USB Type-C™ header, with USB 3.2 Gen 2 support; 1 x USB 3.2 Gen 1 header; 1 x USB 2.0/1.1 header; 2 x temperature sensor headers; 1 x power button; 1 x reset button; 1 x OC button; 2 x BIOS switches; Voltage Measurement Points
Audio: Realtek® ALC1220-VB codec+ESS ES9218P DAC (front panel audio); Realtek® ALC1220-VB codec+ESS ES9018K2M DAC+TI OPA1622 operational amplifier (rear panel audio); Support for DTS:X® Ultra; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF Out
LAN: 1 x Aquantia 10GbE LAN chip (10 Gbit/5 Gbit/2.5 Gbit/1 Gbit/100 Mbit) (LAN1); 1 x Intel® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit) (LAN2)
BIOS: 2 x 256 Mbit flash; Use of licensed AMI UEFI BIOS; Support for DualBIOS™; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor: E-ATX Form Factor; 30.5cm x 27.1cm
OS: Support for Windows 10 64-bit
Other: Intel® Wi-Fi 6 AX201; WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band; BLUETOOTH 5.1; Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
Warranty: 36 Months
