CPU:AM3+ Socket,Support for AMD AM3+ FX processors, Supp. for AMD AM3 Phenom™ II processors / AMD Athlon™ II processors
Chipset:AMD 990FX + AMD SB950
Memory:4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory,Dual channel memory architecture,Supp. for DDR3 2000(O.C.)/1866/1600/1333/1066 MHz memory modules
VGA:No
Expansion Slots:2 x PCI Express x16 slots, running at x16,2 x PCI Express x16 slots, running at x4,2 x PCI Express x1 slots,1 x PCI slot
Connectors:1 x 24-pin ATX main power connector,1 x 8-pin ATX 12V power connector,6 x SATA 6Gb/s connectors,1 x CPU fan header,2 x system fan headers,1 x power fan header,1 x front panel header,1 x front panel audio header,1 x S/PDIF Out header,3 x USB 2.0/1.1 headers,1 x Trusted Platform Module (TPM) header,1 x serial port header,1 x clearing CMOS jumper
Audio:Realtek ALC889 codec,High Definition Audio,2/4/5.1/ 7.1-channel,Support for S/PDIF Out
LAN:1 x Realtek RTL8111E chip (10/100/1000 Mbit)
Rear Panel I/O Ports:1 x PS/2 keyboard/mouse port,1 x optical S/PDIF Out connector,8 x USB 2.0/1.1 ports,2 x USB 3.0/2.0 ports,1 x RJ-45 port,6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
BIOS:2 x 32 Mbit flash,Use of licensed AWARD BIOS,Support for DualBIOS™,PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Form Factor:ATX
